Carriages - Rated by the blade carriage hoisting capacity, there are four sizings of hook type blade carriages. The hook type blade carriages have been standardized.
Class I carriages are rated for cargo as much as 2000 lbs. The carriage bar spacing for Class I is thirteen inches. Class II carriages are rated for loads up to 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
Pin mounted tines vary by the amount of offset between the tine and the blade eye. Different manufacturers would differ the carriages for pin type tines. Carriage capacity will be established by the carriage pin size and by the blade size.
